4.3" TFT HMI Control Panel Industrial HMI Touchscreen Panel Ethernet Port RS485 RS232
Specification:
Model : TK6043FH
Support English, Russian, Spanish, French, Polish, Turkey, Arabia, Chinese etc almost all language and word fonts.
Support Modbus rtu protocol, programming port protocol, fre port protocol.
Features:
- IP65 Panel protection grade, 65K TFT
Brand new high-brightness,high-contrast display LCD, providing colorful operation interface. -
Onboard 408MHz high performance 32Bit industrial grade CPU
has fast running speed,high data processing efficiency and strong anti-interference ability.
-
Thin and light embedded
Can be easily installed in various complex industrial application environments.
-
Data security upgrade
This series of HMl supports password man-agement functions. Users can set passwords for specific registers, buttons,and screens, and add permissions to ensure data security
-
Conformal coating protection for motherboard
In various harsh industrial environments, it is more effective against shock, moisture,high and low temperature, and chemical corrosion.
Dimension | 134*102*32mm |
Cutout size | 120*94mm |
Display size | 97*56mm |
Weight(kg) | Appox. 0.33 kg |
Display | 4.3” TFT |
Resolution (pixels) | 480*272 |
Brightness | 300cd/m² |
Contrast ratio | 400:1 |
Backlight | LED |
Backlight time | 60,000 h |
Display color | 65536 true colors |
Touch type | 4-wire resistive panel |
ROM | 128MB |
RAM | 64MB |
CPU | ARM9 core 400MHz |
Operating system | WINCE 5.0 |
USB port | USB 2.0×1 (USB port and can be connected to external USB flash drive, mouse, etc.) |
Download port | Yes (Mini type B male port cable for program download |
Ethernet port | Optional |
COM port | 1 RS232 and 1 RS485 |
Protocol | Support MODBUS, free port and common PLC communication Protocol |
Audio | Optional |
Calendar | Yes |
Input Voltage | Default as DC12~24±10%V |
Consumption | 150mA*24V |
Protection Class | IP65 (front panel) |
Temperature | Ambient environment: 0～50℃ | Storage environment: -20～70℃ |
Humidity | 20%～90% RH |
Certification | CE |
Software | CoolMay HMI programming software |
